Welcome to Membrane Drain
Membrane Drain gives added waterproofing piece of mind with integrated wall and floor flanges.
The addition of membrane flanges and tile angle with sub-tile drainage weep holes gives added protection to a standard linear shower drain. Most standard systems rely on silicone only as a protective barrier. Make the right choice for your shower drain.
Heelguard offers standard size options or we can customize the system to suit your specific project needs.
| Membrane Drain | Part Number | Material | Grate/Insert Width (mm) | Membrane Flange (mm) | Depth (mm) |
|---|---|---|---|---|---|
 | MD50 | 304 | 50 | 30 | Customize |
| | MD50/316 | 316 | 50 | 30 | Customize |
| | MD80 | 304 | 80 | 30 | Customize |
| | MD80/316 | 316 | 80 | 30 | Customize |
| | MD100 | 304 | 100 | 30 | Customize |
| | MD100/316 | 316 | 100 | 30 | Customize |
| | MD150 | 304 | 150 | 30 | Customize |
| | MD150/316 | 316 | 150 | 30 | Customize |
| Membrane Drain | Part Number | Material | Grate/Insert Width (mm) | Membrane Flange (mm) | Depth (mm) |
|---|---|---|---|---|---|
 | PMD50 | 304 | 50 | 30 | Customize |
| | PMD50/316 | 316 | 50 | 30 | Customize |
| | PMD80 | 304 | 80 | 30 | Customize |
| | PMD80/316 | 316 | 80 | 30 | Customize |
| | PMD100 | 304 | 100 | 30 | Customize |
| | PMD100/316 | 316 | 100 | 30 | Customize |
| | PMD150 | 304 | 150 | 30 | Customize |
| | PMD150/316 | 316 | 150 | 30 | Customize |
Heelguard Wedgewire Grating Options
Standard Finish Options are available in Powdercoat and Plating
Heelguard Wedgewire Grating Options
Standard Finish Options are available in Powdercoat and Plating
| 100 Series Image | Type | Wire Width (mm) | Aperture (mm) | Slip Rating |
|---|---|---|---|---|
 | UNILINE | 5 | 5 | R9 |
 | ECONOLINE | 3 | 5 | R9 |
 | SAFELINE | 5 | 5 | R12 |
 | BROADLINE | 5 | 3 | R9 |
 | FINELINE | 3 | 3 | R9 |
Heelguard Insert and Custom Grating Options
Standard Finish Options are available in Powdercoat and Plating
| 100 Series Image | Type | Wire Width (mm) | Aperture (mm) | Slip Rating |
|---|---|---|---|---|
 | TILELINE | NA | 5 | REFER TILE |
| SLOTLINE | NA | 6 or 10 | NA | |
 | DESIGNER | NA | CUSTOM | R9 |
Projects that use MEMBRANE DRAIN
One Irving Road
PROJECT SHOWCASE: One Irving Road, Toorak Luxury Living Meets Superior Drainage Solutions Located on one of Toorak’s finest tree-lined boulevards, One Irving Road stands as
Northern Aquatic and Community Hub (NACH)
Name: Northern Aquatic and Community Hub (NACH) Stakeholders: City of Greater Geelong, Kane Constructions Location: 1-9 Cox Rd, Norlane VIC 3214 Property / Development Type:
