CIVIL SERIES - Infill Cover & Frame
With a focus on urban streetscape design, the need to provide discreet yet functional drainage products is more important than ever. Heelguard’s Infill covers and frames offer a new solution to the problem of unsightly cast iron infill covers.
Constructed from stainless steel, these lightweight covers offer the most discreet option for pit access covers. With a range of standard and custom size options including multipart covers & frames, we have a solution for every project.
Options
Downloads
Options
| Infill Access Covers & Frames | Part | Material | Clear Opening(mm) | Depth(mm) | Load Class Options (AS3996) |
|---|---|---|---|---|---|
| ICF300 | 304 | 300×300 | Variable | A, B, C, D |
| ICF300/316 | 316 | 300×300 | Variable | A, B, C, D |
| ICF450 | 304 | 450×450 | Variable | A, B, C, D |
| ICF450/316 | 316 | 450×450 | Variable | A, B, C, D |
| ICF600 | 304 | 600×600 | Variable | A, B, C, D |
| ICF600/316 | 316 | 600×600 | Variable | A, B, C, D |
| ICF6090 | 304 | 600×900 | Variable | A, B, C, D |
| ICF6090/316 | 316 | 600×900 | Variable | A, B, C, D |
| ICF750 | 304 | 750×750 | Variable | A, B, C, D |
| ICF750/316 | 316 | 750×750 | Variable | A, B, C, D |
| ICF900 | 304 | 900×900 | Variable | A, B, C, D |
| ICF900/316 | 316 | 900×900 | Variable | A, B, C, D |
| ICF60120 | 304 | 600×1200 | Variable | A, B, C, D |
| ICF60120/316 | 316 | 600×1200 | Variable | A, B, C, D |
| ICF90120 | 304 | 900×1200 | Variable | A, B, C, D |
| ICF90120/316 | 316 | 900×1200 | Variable | A, B, C, D |
| ICF120 | 304 | 1200×1200 | Variable | A, B, C, D |
| ICF120/316 | 316 | 1200×1200 | Variable | A, B, C, D |
Downloads
| Description | |
|---|---|
| Infill Access Covers & Frames | Download |
